Type AVEK –55 °C to +105 °C
Very Long Life - 5000 Hours - SMT Aluminum Electrolytic Capacitors
Recommended Land Patterns by case size for AVEK series
B
A
B
C
Recommended Soldering Methods
Recommended Reflow Soldering Profile:
For case diameters
4 thru 6.3 mm
For case diameters
8 and 10 mm
Case sizes 4 thur 6.3 mm dia. should be subjected to just one reflow soldering process.
The 8 and 10 mm dia. case sizes should be subjected to a maximum of two reflow soldering processes.
Soldering with a solder iron should be performed with a maximum soldering iron tip tem -
perature of 350±5°C for 3 to 4 seconds.
CDE Cornell Dubilier ? 1605 E. Rodney French Blvd. ? New Bedford, MA 02744 ? Phone: (508)996-8564 ? Fax: (508)996-3830 ? www.cde.com
